Error installing STM32CubeMX 6.0.0 on MACOS Monterey 12.6 with M1

Hi @NGadi.1​

According to the user manual of the STM32CubeMX ;

***Software requirements

1-Java™ Runtime Environment

Versions earlier than STM32CubeMX V6.2.0 require a JRE to be installed. The JRE version

constraints are:

• 64-bit version mandatory, 32-bit version not supported

• the STM32PackCreator companion tool requires JRE supporting JavaFX

• minimum JRE version is 1.8_45 (known limitation with 1.8_251)

STMicroelectronics promotes the use of the following JREs:

• Oracle(a), subject to license fee

• Amazon Corretto™(b), no-cost solution based on OpenJDK, JDK installer

recommended.

STM32CubeMX operation is not guaranteed with other JREs

This is the link to download JRE:

https://www.oracle.com/java/technologies/javase/javase8-archive-downloads.html

2-macOS software requirements

• Xcode must be installed on macOS computers

• Both Xcode and Rosetta must be installed on macOS computers embedding Apple®

M1 processor

Installing STM32CubeMX standalone version On macOS:

a) On STM32CubeMX-Mac line, Click “Get software�? to download the package

b) Extract (unzip) the downloaded package.

c) Make sure you have administrator rights.

d) Double-click SetupSTM32CubeMX-VERSION.app application file to launch the

installation wizard.

In case of error, try to fix it: - $sudo xattr -cr ~/SetupSTM32CubeMX-VERSION.app.

Uninstalling STM32CubeMX on macOS®

There are two different ways to uninstall STM32CubeMX on Mac:

1. Move STM32CubeMX.VERSION.app to the trash

2. Use the following command line:

  For STM32CubeMX 6.1.x and older versions only:

java -jar SetupSTM32CubeMX VERSION.app/Contents/Resources/Uninstaller/uninstaller.jar.

Please try to reinstall CubeMX using those steps and do not hesitate to raise any issues or feedback.

Best regards

Ghofrane
