Link_driver failure
Hey everyone,
For some reason I can mount, open and write to a SDcard. Although for some reason I cant use the LinkDriver function.
I have the function setup as if(FATFS_LinkDriver(&SD_Driver, SDPath)==0) and when it enters, it fails because disk.nbr seems to always be 1 no matter what I do.
Does anyone know what could be causing this? I have one sdcard connected in 4bit sdio mode.
A little stumped as it seems to be linked before I even call the function. I also dont have the MX_FATFS_Init(); in the code, so it couldn;t be linked there. Completely Cube generated.
int main(void)
{/* USER CODE BEGIN 1 */
/* USER CODE END 1 */
/* Enable I-Cache-------------------------------------------------------------*/
SCB_EnableICache();/* Enable D-Cache-------------------------------------------------------------*/
SCB_EnableDCache();/* MCU Configuration----------------------------------------------------------*/
/* Reset of all peripherals, Initializes the Flash interface and the Systick. */
HAL_Init();/* USER CODE BEGIN Init */
/* USER CODE END Init */
/* Configure the system clock */
SystemClock_Config();/* USER CODE BEGIN SysInit */
/* USER CODE END SysInit */
/* Initialize all configured peripherals */
MX_GPIO_Init(); MX_DMA_Init(); MX_SDMMC1_SD_Init(); /* USER CODE BEGIN 2 */uint32_t wbytes;uint32_t bytesread;const char wtext [] = 'Hello\0';char rtext[20]= {0}; volatile FRESULT res; volatile FRESULT res1; volatile FRESULT res2; //HAL_SD_Init(&hsd1);if(FATFS_LinkDriver(&SD_Driver, SDPath)==0){
res = f_mount(&SDFatFS,SDPath,1); if(res == FR_OK){ res2 =f_open(&SDFile, 'lat11.txt',FA_CREATE_ALWAYS | FA_WRITE); res1 = f_write(&SDFile, wtext, sizeof(wtext), (void *)&wbytes); // res = f_read(&SDFile, rtext, sizeof(wtext), (void *)&bytesread); f_close(&SDFile); }}
/* USER CODE END 2 */
/* Infinite loop */
/* USER CODE BEGIN WHILE */ while (1) { /* USER CODE END WHILE *//* USER CODE BEGIN 3 */
}
/* USER CODE END 3 */}
#sdmmc #sdio #sdmmc1 #cubemx-project #stm32f7
