hi guys. I'm using stm32l412kb and working with STM32CubeIDE 1.3.0.
I use to use this function when I worked with 8051:
xdata u8 REG_INIT[32] _at_ RAM_Image+0x0020;
and I'm looking for an alternative function

Question

I want to define array [32] at a specific address. This is what I wrote:

#define Step 0x8

#define MainAddress 0x801F800

#define BiasRefInit *(uint64_t *)(MainAddress+ 0*Step)

#define InterREGdelVAL100u *(uint64_t *)(MainAddress+ 1*Step)

#define GaveFactor *(uint64_t *)(MainAddress+ 2*Step)

#define GaveFactorCount *(uint64_t *)(MainAddress+ 3*Step)

#define PowerRecycles *(uint64_t *)(MainAddress+ 4*Step)

#define REG_INIT_FIRST *(uint64_t *)(MainAddress+ 5*Step)

#define MyArray *(uint64_t (*)[32])(MainAddress+ 5*Step)

I cannot access the values in the array but only the whole array. Although the IDE shows me all the (correct) values in the array:

snprintf(string, 8, "%06X", MyArray);

what should i do?

Tesla DeLorean · Answer

>>what should i do?Perhaps use a less hacky approach and use C structures and pointer instead?For a singular pointeruint64_t *MyArray= (uint64_t *)(MainAddress+ 5*Step); // An array, at an addressint i;printf("%p
", MyArray); // The pointerfor(i=0; i<32; i++) printf("%d
", (int)MyArray[i]); // The contentI'd use a structure to define index content with multiple records.Stop using this ugly #define method, and find ways to use the C language
